Description
| CPU | AMD Socket FM2+ Athlon™/A- Series Processors Supports CPU up to 4 cores Supports AMD® Turbo Core 3.0 Technology * Refer to www.asus.com for CPU support list |
| Chipset | AMD A88X (Bolton D4) |
| Memory | 4 x DIMM, Max. 64GB, DDR3 2666(O.C.)/2400(O.C.)/2250(O.C.)/2200(O.C.)/2133/1866/1600/1333 MHz Non-ECC, Un-buffered Memory * Dual Channel Memory Architecture Support AMD Memory Profile (AMP) memory * The Max. 64GB memory capacity can be supported with DIMMs of 16GB (or above). ASUS will update QVL once the DIMMs are available on the market. * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Graphic | Integrated AMD Radeon™ R/HD8000/HD7000 Series Graphics in the A-Series APU Multi-VGA output support : HDMI/DVI-D/RGB ports – Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 1920 x 1200 @ 60 Hz*1 – Supports DVI-D with max. resolution 2560 x 1600 @ 60 Hz – Supports RGB with max. resolution 1920 x 1600 @ 60 Hz Maximum shared memory of 2048 MB AMD® Dual Graphics technology support |
| Multi-GPU Support | Supports AMD 3-Way CrossFireX™ Technology |
| Expansion Slots | 2 x PCIe 3.0/2.0 x16 (Single at x16, dual at x8/x8, red) *2 1 x PCIe 2.0 x16 (max at x4 mode, black) 2 x PCIe 2.0 x1 2 x PCI |
| Storage | AMD A88X FCH(Bolton D4) chipset : 8 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10, JBOD |
| LAN | Intel® I211-AT, 1 x Gigabit LAN Controller(s) |
| Audio | ROG SupremeFX 8-Channel High Definition Audio CODEC – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking – SupremeFX Shielding Technology – ELNA® premium audio capacitors Audio Feature : – DTS Connect – Optical S/PDIF out port(s) at back panel – Sonic SoundStage – Sonic SenseAmp – Sonic Studio – Sonic Radar II |
| USB Ports | ASMedia® USB 3.0 controller : 2 x USB 3.0 port(s) (2 at back panel, blue) AMD A88X FCH(Bolton D4) chipset : 4 x USB 3.0 port(s) (2 at back panel, blue, 2 at mid-board) AMD A88X FCH(Bolton D4) chipset : 8 x USB 2.0 port(s) (2 at back panel, , 6 at mid-board) |
| Special Features | ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 : – The tuning key perfectly consolidates ASUS-exclusive DIGI+ Power Control, TPU, EPU, and Fan Xpert 3 optimize the digital power setting, system performance, power saving and whole system cooling configuration ASUS Exclusive Features : – MemOK! – AI Suite 3 – Ai Charger+ – USB Charger+ – USB 3.0 Boost – Disk Unlocker Interactive HomeCloud – Media Streamer ASUS Quiet Thermal Solution : – Stylish Fanless Design Heat-sink solution & MOS Heatsink – ASUS Fan Xpert 3 ASUS EZ DIY : – ASUS CrashFree BIOS 3 – ASUS EZ Flash 2 – ASUS UEFI BIOS EZ Mode – Push Notice ASUS Q-Design : – ASUS Q-Shield – ASUS Q-Code – ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) – ASUS Q-Slot – ASUS Q-DIMM – ASUS Q-Connector |
| Back I/O Ports | 1 x PS/2 keyboard/mouse combo port(s) 1 x DVI-D 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) port(s) 4 x USB 3.0 (blue) 2 x USB 2.0 1 x Optical S/PDIF out 6 x Audio jack(s) 1 x USB BIOS Flashback Button(s) |
| Operating System Support | Windows® 8.1 32/64-bit Windows® 8 32/64-bit Windows® 7 32/64-bit |
| Internal I/O Ports |
1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) 1 x TPM header 8 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x CPU OPT Fan connector(s) (1 x 4 -pin) 3 x Chassis Fan connector(s) (3 x 4 -pin) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x DRCT header(s) 1 x MemOK! button(s) 1 x Slow Mode switch(es) 7 x ProbeIt Measurement Points 1 x Power-on button(s) 1 x Reset button(s) 1 x Clear CMOS button(s) 1 x LN2 Mode jumper(s) 1 x ROG extension (ROG_EXT) header(s) 1 x KeyBot Button 1 x Sonic SoundStage Button |
| Accessories | User’s manual I/O Shield 4 x SATA 6Gb/s cable(s) 1 x Q-connector(s) (2 in 1) 1 x 12 in 1 ROG Cable Label(s) 1 x ROG Door Hanger(s) 1 x ROG Mouse Mat |
| BIOS | 64Mb UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI5.0a, Multi-Language BIOS |
| Manageability | WfM 2.0, DMI 2.7, WOL by PME, PXE |
| ROG Exclusive Features |
Extreme Engine Digi+ III :
– Full Digital CPU/DRAM Power – NexFET™ Power Block MOSFET – New Alloy Chokes – 10K Black Metallic Capacitors ROG Extreme OC kit : – Slow Mode – LN2 Mode ProbeIt KeyBot – CPU Level Up – XMP – Direct Key UEFI BIOS features : – GPU.DIMM Post – Tweakers’ Paradise – ROG SSD Secure Erase – Graphic Card Information Preview ROG RAMDisk GameFirst III Extreme Tweaker USB BIOS Flashback |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| Support Disc | Drivers ROG GameFirst III ROG RAMDisk ROG CPU-Z Kaspersky® Anti-Virus DAEMON Tools Pro Standard ASUS WebStorage HomeCloud ASUS Utilities |
