Description
| Essentials | ||
| Processor Number | i3-4160 | |
| Status | Launched | |
| Launch Date | Q3’14 | |
| Lithography | 22 nm | |
|
Performance
|
||
| # of Cores | 2 | |
| # of Threads | 4 | |
| Processor Base Frequency | 3.60 GHz | |
| Cache | 3 MB SmartCache | |
| Bus Speed | 5 GT/s DMI2 | |
| TDP | 54 W | |
|
Memory Specifications
|
||
| Max Memory Size (dependent on memory type) | 32 GB | |
| Memory Types | DDR3-1333/1600, DDR3L-1333/1600 @ 1.5V | |
| Max # of Memory Channels | 2 | |
| Max Memory Bandwidth | 25.6 GB/s | |
| ECC Memory Supported ? | Yes | |
|
Graphics Specifications
|
||
| Processor Graphics ? | Intel? HD Graphics 4400 | |
| Graphics Base Frequency | 350.00 MHz | |
| Graphics Max Dynamic Frequency | 1.15 GHz | |
| Graphics Video Max Memory | 2 GB | |
| Graphics Output | eDP/DP/HDMI/DVI/VGA | |
| Max Resolution (HDMI 1.4)? | 4096×2304@24Hz | |
| Max Resolution (DP)? | 3840×2160@60Hz | |
| Max Resolution (eDP – Integrated Flat Panel)? | 3840×2160@60Hz | |
| Max Resolution (VGA)? | 1920×1200@60Hz | |
| DirectX* Support | 11.1/12 | |
| OpenGL* Support | 4.3 | |
| Intel? Quick Sync Video | Yes | |
| Intel? InTru? 3D Technology | Yes | |
| Intel? Wireless Display | Yes | |
| Intel? Clear Video HD Technology | Yes | |
| # of Displays Supported ? | 3 | |
| Device ID | 0x41E | |
|
Expansion Options
|
||
| Scalability | 1S Only | |
| PCI Express Revision | Up to 3.0 | |
| PCI Express Configurations ? | Up to 1×16, 2×8, 1×8+2×4 | |
| Max # of PCI Express Lanes | 16 | |
|
–
Package Specifications |
||
| Sockets Supported | FCLGA1150 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG 2013C | |
| TCASE | 72?C | |
| Package Size | 37.5mm x 37.5mm | |
| Low Halogen Options Available | See MDDS | |
|
Advanced Technologies
|
||
| Intel? Turbo Boost Technology ? | No | |
| Intel? vPro Technology ? | No | |
| Intel? Hyper-Threading Technology ? | Yes | |
| Intel? Virtualization Technology (VT-x) ? | Yes | |
| Intel? Virtualization Technology for Directed I/O (VT-d) ? | No | |
| Intel? VT-x with Extended Page Tables (EPT) ? | Yes | |
| Intel? TSX-NI | No | |
| Intel? 64 ? | Yes | |
| Instruction Set | 64-bit | |
| Instruction Set Extensions | SSE4.1/4.2, AVX 2.0 | |
| Idle States | Yes | |
| Enhanced Intel SpeedStep? Technology | Yes | |
| Thermal Monitoring Technologies | Yes | |
| Intel? Stable Image Platform Program (SIPP) | No | |
| Intel? Small Business Advantage | Yes | |
|
Intel? Data Protection Technology
|
||
| Intel? AES New Instructions | Yes | |
| Secure Key | Yes | |
|
Intel? Platform Protection Technology
|
||
| Trusted Execution Technology ? | No | |
| Execute Disable Bit ? | Yes | |
